Friday, April 25, 2014

Tern Link P7i and Swoop D7


Tern is a new folding bike company, which split from Dahon. They now offer a wide range of folding bike designs. Similar to Bike Friday and Brompton folding bikes, there are meant for people who want to travel with their bike, who need to keep a bike in small space, or who have a multi-modal commute which does not allow standard-sized bikes.
Tern Link P7i
The Link P7i, "The equipped one" as they say, comes with almost everything you could want. Dynamo hub and lights, a Shimano Nexus 7-speed internal gear hub, rear rack, fenders, and chainguard  (attached directly to the chain) are included. There is a bracket on the front of the frame to attach a bag or front basket, which does not affect the steering. It is available for $1200 at Clever Cycles and other shops.
Tern also sells the Swoop d7i for $1000. It also has a rear rack and optional dynamo lighting, with a 7-speed hub, and a standard chainguard.
Tern Swoop d7i
And at the high end, they offer an Alfine 11 speed IGH equipped bike with disc brakes and dynamo lighting, the Eclipse S11i:
Tern Eclipse S11i
Reviews:
NYCEWheels Video - Eclipse S11i
Lovely Bicycle - Swoop d7i
London Cyclist - Link
Turbo Bob - Link

Specifications:

Link p7i
GENERAL INFO
Color: (Black/Grey)
Wheel Size:20 inch wheels
Speeds:7
Weight:14.2 kg
Folding Time:10 sec
Folding Size:38 x 79 x 72 cm
Frame Sizes:One size
Gear Inches:33" - 81"
Rider Height:142 - 190 cm
Max Rider Weight:110 kg
FRAME
Frame:6061-Alumnium
Fork:Aluminum, 6061-AL
COCKPIT
Handlepost:Physis T-Bar, aluminum,
Stem:Andro
Headset:cartridge bearings
Handlebar:K6061-AL
Grip/Bars Tape:BioLogic Arx
Saddle:BioLogic Como PRM
Seatpost:BioLogic PostPump 2.0
Seatpost Clamp:Syntace, stainless bushing
BRAKES
Brakes: V-brakes
Brake Levers:BioLogic integrated bell


WHEELS
Front Hub:BioLogic Joule II dynamo
Rear Hub:Shimano Nexus 7
Spokes and Nipples:Stainless steel, brass nipples
Rims:Kinetix Comp by WTB, doublewall, CNC sidewalls, powder finish
Tires:Schwalbe Marathon Supreme, 42-406, RaceGuard puncture protection, Reflex
TRANSMISSION
Shifter(s):Shimano 7 spd twist
Crankset:Kinetix Supra, forged 6061 cranks, 6061 chainring, CNC chainguard
Cassette/Freewheel:SRAM for hub gear
Bottom Bracket:Cartridge, sealed bearings
Chain:RustBlock, GST coated, 3/32"
Pedals:Suntour folding, alloy body


EXTRAS
Chainguard:BioLogic FreeDrive
Kickstand:Premium single, aluminum
Clip System:Magnetix 2.0
Luggage Socket:Yes
Front Light:Valo, HiLux LED with StandLight
Rear Light:Spanninga Premium, LED
Fenders:SKS, stainless hardware
Rack(s):BioLogic Portage 20, tubular aluminum, KlickFix compatible




Eclipse
GENERAL INFO
Color: (Black/Polish)
Wheel Size:24 inch wheels
Speeds:11
Weight:14.7 kg
Folding Time:10 sec
Folding Size:42 x 89 x 76 cm
Frame Sizes:One size
Gear Inches:30" - 120"
Suggested Rider Height:148 - 195 cm
Max Rider Weight:115 kg
FRAME
Frame:7005-AL TIG welded
Fork:aluminum, 6061-AL
COCKPIT
Handlepost:forged aluminum
Stem:Andros,
Headset:cartridge bearings
Handlebar:double-butted 7050-AL
Grip/Bars Tape:Ergon GP1 BioKork
Saddle:Kore Sola for Tern
Seatpost:7050-AL
Seatpost Clamp:Syntace, stainless bushing
BRAKES
Brakes & Levers:Avid Elixir

WHEELS
Front Hub:BioLogic Joule HG, disc
Rear Hub:Shimano Alfine, 11-speed
Spokes and Nipples:Double-butted 18/10 stainless,
Rims:Kinetix Pro, niobium alloy
Tires:Big Apple 50-507
TRANSMISSION
Shifter(s):Shimano Alfine, 11 spd.
Crankset:FSA Vero, ISIS BB, CNC Guard
Cassette/Freewheel:Shimano for hub gear
Bottom Bracket:American Classic, ISIS
Chain:RustBlock, GST coated, 3/32"
Pedals:MKS EZY QR
Shifter Cable & Housing:Shimano
EXTRAS
Chainguard:BioLogic FreeDrive
Kickstand:Premium single, aluminum
Clip System:Magnetix 2.0
Luggage Socket:Yes
Front Light:Valo, HiLux LED with StandLight
Rear Light:Spanninga Premium, LED
Fenders:SKS, stainless hardware
Rack(s):BioLogic Portage Racks
